Automatic Water Level Controller Cum Indicator

Automatic Water Level Controller Cum Indicator Save Water, Protects Moter And Reduces Electricity Bill New Box pic with 1 year warranty .

Features:
LIAMOCON switches on the motor if:
The water in overhead tank falls to prefixed low level i.e., below 75%, 50%, 25% as adjusted.
The sump is full irrespective of any levels in the over head tank at once when power comes
Soft touch NEED in case to Switch on the motor in any irrespective of any level in the over head tank
The switch is in manual position

LIAMOCON switches off the motor for the following reasons:
Liquid reaches maximum level in the over head tank
There is a low or high voltage
Liquid in the sump goes below foot valve or as prefixed low level
Liquid does not flowing to the over head tank
The switch is in off position
Fuse blown off

Front Facia of Liamocon:
Show clear indication of water levels in the over head tank and sump tank
Shows voltage variation if any in the left bottom corner, it shows green indicator for normal voltage, higher red light indicates high voltage and lower red light indicates low voltage
Has an easy operate able AUTO MANUAL feather switch
Green indicates AUTO Mode, Orange indicates dry running of motor
Soft touch 'NEED' in case to switch on the motor irrespective of any level in the overhead tank
Soft touch 'SILENCE' for silencing alarm
Blinking green light indicates liquid flow to overhead tank
Red indication with beeping sound for over flowing of water from over head tank
Side leap switch enables to power on and off Direct on for motor

Gives Alarm:
When there is a voltage fluctuation
When the motor is dry running due to footvalve blockage or priming fault in motor
When water overflows from the overhead tank at 'MANUAL' Mode>

Applications:
Automatic water level Controller for hotels, Factories, Homes, Apartments, Commercial Complexes, Drainage, etc
It can be fixed for single phase motor, single phase Submersibles, Three phase motors. (For three phase and Single phase Submersible Starter is necessary) and open well, Bore well, Sump. We can control two motor & two sumps & two
over head tanks by a single unit (Auto Change Over). Many models available different range
